Online Checkweigher


Online Checkweigher

Specifications

Brand Target
Application Online Weighing
Material Stainless Steel
Weighing Range 30g to 1000g
Belt speed 20mtrs/min (variable based on product size)
Power requirements 1phase, 220V, 50Hz.
Machine weight 80/100kgs
MOC Mild Steel, Stain less steel.
Weighing conveyor size 400mm X 400mm (LXW)
Accuracy 2g
Product Output Range 60 to 80PPM
Display Graphics LCD display
Controller PLC based
Operation Panel Feather Touch
Memory Capacity Custom Made Available
Communication Ethernet and Modbus (custom made possible, on demand)
Product size LBH-30x30x50mm , Dia-30~50mm, Height-50~80mm

Additional Information

Product Code TCW
Min. Order Quantity 1 Piece(s)

In motion check weigher is designed with the latest technology to achieve higher accuracy in dynamic weighing.
It simplifies total product weight control it improves production line profiles by segregating under / over weigh packages from the ones which are within acceptable limits.

Aplicatioons industries:

  • Pharmaceutical
  • Food & Beverages
  • Cosmetics
  • Chemicals
  • Engineering
